RIGOL DC Power Supply DP711

RIGOL DC Power Supply DP711

Programming Resolution 10mV/10mA

Readback Resolution 10mV/10mA

Output Ripple and Noise < 500μVrms

Total Power 150W

Display Resolution 10mV/10mA

Communication Interface RS232

Output Per Channel 30V/5A

Delivery：1 Week

Standard Accessories

Quantity：

€295.00 excl. VAT

€351.05 incl. 19% VAT

Buy Now Add to cart Add to wish list

Description
DP700 Power Supply Model
Feature & Video
Datasheet & Manual Download

Add To Cart

Model	Market Price	Price	Delivery	Programming Resolution	Output Ripple and Noise	Readback Resolution	Total Power	Display Resolution	Communication Interface	Output Per Channel	Operation
RIGOL DC Power Supply DP711	€295.00	€295.00	1 Week	10mV/10mA	< 500μVrms	10mV/10mA	150W	10mV/10mA	RS232	30V/5A
RIGOL DC Power Supply DP712	€295.00	€295.00	1 Week	10mV/10mA	< 500μVrms	10mV/10mA	150W	10mV/10mA	RS232	50V/3A

Low Ripple Noise

Ultra low noise design (< 500uvrms / 3mvpp), to meet the user's demand for high purity power supply
Fast transient response

When the transient response time is less than μ s50 , when the load current changes, the output voltage can quickly return to the set value to ensure the output quality.
Excellent power & load regulation

0.01% power regulation rate and load regulation rate to ensure the stability and safety of output.
Convenient trigger function

When multiple power supplies are connected in series or in parallel, the external trigger function can make multiple power supplies output synchronously.
Timing output function

When the timing output is on, the voltage and current values of different periods can be configured according to the preset timer parameters to provide varying voltage and current output for the load
OVP & OCP

Perfect over-voltage / over-current protection (OVP / OCP), the user can set the limit value of over-voltage and over-current protection, when over-voltage or over-current occurs, the power will automatically shut down the output and give a prompt message.

Manual Download

File Name	Version	Release Date	Operation
DP700 Datasheet	V1.0	8/29/2019	Download
DP700 Programming Manual	V1.0	8/29/2019	Download
DP700 QuickGuide	v1.0	11/25/2021	Download
DP700 User Manual	V2.0	6/21/2024	Download
